| Specs |
|
Outer Hole 5/16"
S/F Formed
Specially designed center hole to replace six point star
Equipment Type Lawn Mower
Sold individually
Deck Size 46" Cut
Center Hole 6 Point Star
Length 16-1/4"
Center To Center 2-1/2"
Thickness .149"
Width 2.5"
Type High Lift
|
| Fits Model |
MTD : 1997 and newer held on with nut; requires 2 of 335-691 and 1 of 335-695 for 46" cut
TORO : 13AX60RH744; requires 2 of 335-691 and 1 of 335-695 for 46" cut
TROY BILT : Requires 2 of 335-691 and 1 of 335-695 for 46" cut
CUB CADET : (2) of 335-691 & (1) of 335-695 for 46" deck
|
| Replaces OEM |
|
Bolens :
7420611
1772144
|
|
|
|
|
|
| |
| Specs |
|
Outer Hole 5/16"
S/F Formed
Requires 1 of 335-695 and 2 of 335-691 for 46" deck
Specially designed center hole to replace six point star
Equipment Type Lawn Mower
Sold individually
Deck Size 46" Cut
Center Hole 6 Point Star
Length 14-7/8"
Center To Center 2-1/2"
Thickness .149"
Width 2.5"
Type High Lift
|
| Fits Model |
MTD : 1997 and newer, held on with nut; requires 1of 335-695 and 2 of 335-691 for 46" decks
TORO : 13AX60RH744; requires 1 of 335-695 and 2 of 335-691 for 42" decks
TROY BILT : Auto drive step thru, 1999 and older; reuqires 1 of 335-695 and 2 of 335-691 for 46" decks
|
| Replaces OEM |
|
Bolens :
7420612
9420612
9420612A
|
|
|
|
|
|
| |
| Specs |
|
Equipment Type Lawn Mower
Length 21-3/16"
Center Hole 5/8 Y; 6 Pt. Star
Outer Hole 5/16"
Center To Center 2-1/2"
Width 2.75"
Thickness .149"
Offset 3/8"
Air Lift 1-1/2"
|
| Fits Model |
|
| Replaces OEM |
|
Bolens :
7420616
7420616A
9420616
9420616A
|
|
|
|
|
|
| |
| Specs |
|
Outer Hole 5/16"
S/F Formed
Specially designed center hole to replace six point star
Equipment Type Lawn Mower
Sold individually
Deck Size 38" Cut
Thickness .149"
Center Hole 6 Point Star
Length 19-1/4"
Center To Center 2-1/2"
Width 2.75"
Type Mulching
|
| Fits Model |
MTD : 400 and 600 series 38" cut 1997 and newer
TROY BILT : Requires 2 for 38" cut
|
| Replaces OEM |
|
Bolens :
7420610
9420610
|
|
|
|
|
|
| |
| Specs |
|
Width 3"
Outer Hole 5/16"
Thickness .149"
S/F Formed
Specially designed center hole to replace six point star
Requires 2 for 38" cut
Equipment Type Lawn Mower
Sold individually
Deck Size 38" Cut
Center Hole 6 Point Star
Length 19-1/4"
Center To Center 2-1/2"
Type High Lift
|
| Fits Model |
MTD : (2) for 38" cut, fits deep decks 1997 and newer, auto drive step through frame lawn tractors
TROY BILT : (2) for 38" cut, fits 700 series
|
| Replaces OEM |
|
Bolens :
9420610
9420610A
|
|
|
|
|
|
| |
| Specs |
|
Equipment Type Lawn Mower
Length 21-3/16"
Center Hole 5/8 Y; 6 Pt. Star
Outer Hole 5/16"
Center To Center 2-1/2"
Width 3"
Thickness .149"
Offset 5/16"
Air Lift 1-1/4"
|
| Fits Model |
|
| Replaces OEM |
|
Bolens :
7420616
7420616A
9420616
9420616A
|
|
|
|
|
|
| |
| Specs |
|
Length 22"
Width 2 1/4"
Center Hole 15/16" X 11/16"
Outer Hole 5/16"
Center To Center 2 1/2"
Thickness 119"
S/F Formed
Equipment Type Walk Behind Lawn Mower
Sold individually
Deck Size 22" Cut
Type Mulching
|
| Fits Model |
MTD : 22" walk behind decks 1995 and newer
|
| Replaces OEM |
|
Bolens :
7420742A
|
|
|
|
|
|
| |
| Specs |
|
Type Mulching
Specially deisgned center hole to replace six point star
Sold individually
Width 2.75"
Outer Hole 5/16"
Length 21-1/4"
S/F Formed
Center To Center 2-1/2"
Thickness .149"
Center Hole 6 Point Star
Equipment Type Lawn Mower
Deck Size 42" Cut
|
| Fits Model |
MTD : 1997 and newer and autodrive step-thru framelawn tractors 1999 and newer; requires 2 for42" cut
TORO : 13AX60RG744, requires 2 for 42" cut
TROY BILT : 2006-2010; Requires 2 for 42" deck
|
| Replaces OEM |
|
Bolens :
7420616
9420616
9420616A
|
|
|
|
|
|
| |
| Specs |
|
Equipment Type Lawn Mower
Lead Length 16-1/4"
Center Hole 5/8 Y; 6 Pt. Star
Outer Hole 3/8"
Center To Center 2-1/2"
Width 2.50"
Thickness .149"
Air Lift 1-1/8"
Offset 7/16"
|
| Fits Model |
|
| Replaces OEM |
|
Bolens :
7420611
7420611A
9420611
9420611A
|
|
|
|
|
|
| |
| Specs |
|
Deck Size 38" Cut
Equipment Type Lawn Mower
Length 19 5/16"
Offset 5/16"
Outer Hole 5/16"
Sold Individually
Width 3"
Center Hole 5/8 Y; 6 Pt. Star
Thickness .164"
Air Lift 1-1/4"
|
| Fits Model |
MTD : (2) for 38" cut, use in place of out 98-058 for non-mulching
|
| Replaces OEM |
|
Bolens :
7420610
7420654
9420610
9420654
|
|
|
|
